Name: BTTZ
Brand: Jiangxi Zhi Lian Wire & Cable Co., Ltd.
Availability: InStock
Rating: 5 (1 reviews)

Description

Features

BTTZ power cable is a rigid mineral insulated cable with copper core, copper sheath, and magnesium oxide insulation. Its core features focus on "ultimate fire resistance, high temperature resistance, strong protection, and long durability", making it the core distribution choice for high-risk emergency scenarios. It can work at a temperature of up to 250 ℃ for a long time, and can provide short-term power supply under the extreme state of 1000 ℃. It neither self ignites nor supports combustion in case of fire, nor produces toxic smoke. It can continue to be used without replacement after a fire. Its seamless copper sheath combines strong mechanical strength and sealing performance, and can be waterproof, corrosion-resistant, and explosion-proof. It can still work normally even when deformed by compression to half of its original diameter, and can be directly used as a grounding wire. At the same time, it has a large current carrying capacity, strong overload capacity, and is made of all inorganic materials to prevent aging problems. Its service life far exceeds that of ordinary cables, and it also has the characteristics of radiation resistance and electromagnetic interference prevention, suitable for various harsh working conditions.

Applications

The application scenarios of BTTZ power cables focus on high-risk and emergency power distribution. They are used for fire emergency circuits in densely populated areas such as high-rise buildings, hospitals, and subways, as well as for distribution lines in flammable and explosive environments such as petrochemicals and mines. They can also be applied to power critical facilities such as nuclear power plants and data centers that have extreme requirements for fire and explosion prevention, meeting the safety power supply needs of high-risk, emergency, and critical scenarios.

Specification Parameters

Model	Cross Section	Voltage	Conductor	Strands	Cores
BTYZ 1*16	1*16mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*25	1*25mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*35	1*35mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*50	1*50mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*70	1*70mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*95	1*95mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*120	1*120mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*150	1*150mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*185	1*185mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*240	1*240mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 1*300	1*300mm²	450/750v	Oxygen-Free Copper	1	1
BTYZ 5*4	5*4mm²	450/750v	Oxygen-Free Copper	1	5
BTYZ 5*6	5*6mm²	450/750v	Oxygen-Free Copper	1	5
BTYZ 5*10	5*10mm²	450/750v	Oxygen-Free Copper	1	5
BTYZ 5*16	5*16mm²	450/750v	Oxygen-Free Copper	1	5
